Family of surface mount and pendant led linear Decorative operating at 25w/m, 220-240 VAC input.delivering out standing performance of 700lm/m.

فهرست مطالب

[et_pb_section bb_built=”1″ specialty=”on” _builder_version=”3.3.1″ custom_margin=”||0px|” custom_padding=”||0px|”][et_pb_column type=”1_4″][et_pb_sidebar _builder_version=”3.18.1″ area=”et_pb_widget_area_6″ custom_margin=”|||0px” custom_padding=”|||0px” /][/et_pb_column][et_pb_column type=”3_4″ specialty_columns=”3″][et_pb_row_inner admin_label=”Row”][et_pb_column_inner type=”4_4″ saved_specialty_column_type=”3_4″][et_pb_sidebar _builder_version=”3.3.1″ area=”et_pb_widget_area_4″ show_border=”off” text_orientation=”left” custom_margin=”0px|||” custom_padding=”0px|||” /][et_pb_text _builder_version=”3.15″ custom_margin=”0px|||” custom_padding=”0px|||”]

LIOSA MID & NARROW

Decorative

[/et_pb_text][/et_pb_column_inner][/et_pb_row_inner][et_pb_row_inner admin_label=”Row” _builder_version=”3.18.1″ custom_margin=”0px||0px|” custom_padding=”0px||0px|” animation_style=”fold”][et_pb_column_inner type=”1_2″ saved_specialty_column_type=”3_4″][et_pb_code _builder_version=”3.18.1″ animation_style=”fade”]

[/et_pb_code][/et_pb_column_inner][et_pb_column_inner type=”1_2″ saved_specialty_column_type=”3_4″][et_pb_gallery _builder_version=”3.18.1″ gallery_ids=”6778,3768″ zoom_icon_color=”#2ea3f2″ hover_overlay_color=”rgba(255,255,255,0.9)” show_title_and_caption=”off” border_width_all_image=”1px” border_color_all_image=”#bcbcbc” posts_number=”1″ animation_style=”fade” /][/et_pb_column_inner][/et_pb_row_inner][et_pb_row_inner admin_label=”Row” _builder_version=”3.3.1″ custom_margin=”0px|||” custom_padding=”0px|||”][et_pb_column_inner type=”1_2″ saved_specialty_column_type=”3_4″][et_pb_text _builder_version=”3.15″]

Technical description

Luminaire for indoor architectural linear lighting, LED color temperature is 3000- 6000 kelvin. A surface LED luminaire, flat direct light distribution with 20 mm opaque PMMA diffuser and body: extruded anodize aluminum (powder coating an option). Class I electrical, IP44 (IP54 only for option). Total power: 25 w/m, slave luminaire for DALI control (an option only) with LED converter. Chromaticity tolerance (initial MacAdam: 3). Color rendering Ra> 80.
Can be produced in lengths of 860, 1150 and 1700 mm.

Dimensions: 1700 x 40 x 100 mm
Total power: 42.5 w
Luminaire luminous flux: 1190 lm
Luminaire efficacy: 28 lm/w
Weight: 2 kg/m

[/et_pb_text][/et_pb_column_inner][et_pb_column_inner type=”1_2″ saved_specialty_column_type=”3_4″][et_pb_text _builder_version=”3.15″]

Installation and Mounting

Surface-mounted (ceiling) using accessories to be ordered separately.

[/et_pb_text][et_pb_text _builder_version=”3.15″]

Application

  • ALUCOD ceiling
  • Shopping mall
  • Exhibition hall
  • Food court

[/et_pb_text][/et_pb_column_inner][/et_pb_row_inner][et_pb_row_inner admin_label=”Row”][et_pb_column_inner type=”4_4″ saved_specialty_column_type=”3_4″][et_pb_code _builder_version=”3.15″][ninja_tables id=”3783″][/et_pb_code][et_pb_code _builder_version=”3.15″][ninja_tables id=”4849″][/et_pb_code][/et_pb_column_inner][/et_pb_row_inner][/et_pb_column][/et_pb_section]
